Mountz TBX Break-Over Wrenches
Engineered and assembled in Silicon Valley, the Mountz TBX line of precision preset break-over wrenches ensures consistent process and quality control by providing operators with a break-over wrench that helps you support your quality control inspectors by empowering your workers to prevent assembly errors. Torque range suitable for low to higher torque applications.
Designed to tighten diverse fasteners accurately, break-over wrenches inform their operator when the right torque is reached by deflecting on their built-in hinge. As a result, you can reduce defective products and rework related to over- and under-torque conditions.
Their small size enables them to fit into areas with tight clearances, boosting productivity and project ROI.
With interchangeable heads, Mountz break-over wrenches allow you to switch out heads for tricky fasteners and to get more use out of your existing tools.
NOTE: Head interchangeability is intended for use during recalibration to allow reconfiguring tools for different applications. They are not intended to be interchanged as a normal part of a manufacturing process.
TBX break-over wrenches have a calibration life of 4x ISO standards that is unmatched by any click wrench on the market to keep your tools out of the lab and on the production floor.
Safeguarding Against Fastening Failures
- Torque limiting wrench improves control of the tightening process and reduces the risk of over and under-tightening
- The preset wrench ensures that the correct torque value is consistently applied to each fastener by reducing the risk of the operator tampering with settings.
- The break-over mechanism deflects 20° on torque delivery, visually indicating torque is achieved. The break-over angle can be changed to 90° with only the TBX-12 models by removing the Stop Collar
- Interchangeable end fitting design—selectable head types and sizes.
- Our products are reliable and durable; Calibration life 4x ISO standards, unmatched by any click wrench.
- Description
- Reviews (0)
Description
The Mountz TBX break-over wrench is a preset torque wrench for connectors, brackets and small assemblies in Singapore. When the set value is reached the head breaks over, so the operator feels the stop and cannot keep adding torque. Two sizes cover 2.4 to 25 N·m, and both come in ESD versions.
CHOOSE THE MODEL BELOW
| Model | Item Name / Number | American | S.I. | Drive Size | |
|---|---|---|---|---|---|
 |
TBX-12 | 076815 | 21.2 – 106.2 lbf.in | 2.4 – 12 N.m | Type A |
 |
TBX-12 ESD | 076818 | 21.2 – 106.2 lbf.in | 2.4 – 12 N.m | Type A |
 |
TBX-25 | 076816 | 44.3 – 221.3 lbf.in | 5 – 25 N.m | Type B |
 |
TBX-25 ESD | 076819 | 44.3 – 221.3 lbf.in | 5 – 25 N.m | Type B |
Error-Proofing
-
-
- Torque limiting wrench improves control of the tightening process, reducing the risk of over and under-tightening to deliver repeatability, traceability, and precision for tightening applications.
- A preset wrench ensures that the correct torque value is applied consistently to each fastener by reducing the risk of the operator tampering with settings. This tool has no external adjustment scale and is set using a torque analyzer.
-
Advanced Technology
-
-
- Unique interchangeable end fitting design— we offer selectable head types and sizes, including open end, box head, hex key, fixed square drive heads, and ratchet heads.
- We manufacture interchangeable heads with a common centerline, so the torque setting remains unchanged when changing head sizes.
-
Process Improvement
-
-
- The break-over mechanism provides a visual indicator of achieving torque setting, improving productivity. The tool only operates in a CW direction.
-
Mountz Quality Standards
-
- Our tools are durable and reliable. Calibration life 4x ISO standards to keep your tools out of the lab and on the production floor.
- ESD-safe models are available for purchase.
The preferred and certified ranges of these tools is in accordance with the requirements of ISO 6789 (+/- 4% of indicated setting).
The flexible TBX torque wrench can adapt to various interchangeable head fittings.
Head options for TBX-12 model:
- Open End
- Box Head End
- Hex Key
- Ratchet Head
- Box Ratchet Head
- Fixed Head
- Blank End
Head options for TBX-25 model:
- Open End
- Box Head End
- Ratchet Head
- Blank End
Calibration & Service:
- Torque Analyzers & Sensors: If torque tools slip out of calibration, that could impact the quality of your products. An accurate way to regularly test calibration onsite is a great way to reduce risk and ensure safety. With Mountz torque analyzers and sensors, you can test tools before they go into service daily or weekly.
- Hex Step Adapters: When performing torque wrench calibration or testing, adapters are often needed, especially with torque wrenches with open-end heads. Mountz’s calibration hex step adapter features three or four common sizes, increasing the productivity of your torque wrench calibration process.
Where it fits in Singapore
The TBX break-over head hinges at the set torque — an unmistakable stop signal that suits Singapore MRO and maintenance teams working on fittings and fasteners where a clear, physical cue beats listening for a click in a noisy hangar or plant. Compare mechanisms with the IPT click and FGC cam-over wrenches under Torque Wrenches, and see our tool-selection guide. Phil Industries is an authorised Mountz distributor in Singapore — call +65 6555 1745 or WhatsApp +65 9853 9030.
TBX break-over wrench at a glance
| Type | Preset break-over (breaking) torque wrench |
| Range | 2.4 – 12 N·m (TBX-12) and 5 – 25 N·m (TBX-25) |
| Models and part numbers | TBX-12 (076815), TBX-12 ESD (076818), TBX-25 (076816), TBX-25 ESD (076819) |
| Heads | Interchangeable TBX-12 (Type A) and TBX-25 (Type B) heads |
| ESD | ESD versions for use inside an ANSI/ESD S20.20 protected area |
| Standard | Certified to ISO 6789 |
Where the TBX break-over wrench fits in Singapore
The TBX is the wrench of choice for RF and fibre connectors, telecom racks and PCB-mounted hardware in Singapore EMS plants. Because the ESD version dissipates charge, it can also stay on the bench inside an EPA. Moreover, interchangeable heads mean one calibrated handle serves several connector sizes.
Pair it with
- TBX-12 wrench heads for the 2.4 – 12 N·m handle.
- TBX-25 wrench heads for the 5 – 25 N·m handle.
- Mountz torque analyzers to verify the break-over point.
Frequently asked questions about the TBX break-over wrench
What is a breaking or break-over torque wrench
It is a preset wrench whose head pivots when the set torque is reached. The operator feels a clear stop, so almost no extra torque passes after the signal.
Is the TBX ESD safe
The TBX-12 ESD and TBX-25 ESD versions are made for static-sensitive work, so they can be used inside an EPA. The standard versions are for general assembly.
Can I change heads on the TBX
Yes. TBX-12 handles take Type A heads and TBX-25 handles take Type B heads, which lets one calibrated handle serve several fastener or connector sizes.
TBX or TB: what is the difference
The TB covers lower values from 17.7 to 565 cN·m with a fixed head. By contrast, the TBX reaches 25 N·m and takes interchangeable heads.
Need help choosing a model? Message our Singapore engineers on WhatsApp at +65 9853 9030, call +65 6555 1745 or email sales@phil-industries.com.sg for a quotation, a stock check or an on-site demonstration.
Related Mountz pages in Singapore
- Browse all Break-over Wrenches and the wider Torque Wrenches range.
- See the full Mountz torque tools range in Singapore.
- Read our engineers’ guides to torque control basics and choosing between a torque wrench, screwdriver or multiplier.
- Verify tool output in-house with the Mountz EZ-TorQ III torque analyzer.
Phil Industries, an authorised Mountz distributor in Singapore, supplies this product with selection advice and after-sales support. Call +65 6555 1745, WhatsApp +65 9853 9030 or email sales@phil-industries.com.sg.
