Dark Blue 135GSM Knitted Polyester ESD Fabric, 5mm Diamond
| Brand Name: | ESDpro |
| Certification: | ISO/SGS |
| Model Number: | AF0632 |
- Description
- Additional information
- Reviews (0)
Description
This knitted ESD fabric is available in Singapore from Phil Industries. 5mm Diamond Pattern Knitted Polyester ESD Fabric Dark Blue 135 GSM Weight provides reliable ESD protection for cleanroom and electronics manufacturing environments. As a supplier of ESD fabric in Singapore, Phil Industries offers island-wide delivery on all knitted ESD fabric products.
Detailed Product Description
5mm Diamond Pattern Knitted Polyester ESD Fabric Dark Blue 135 GSM Weight
ESD Knitted Fabric 5mm Diamond Pattern: AF0632
Description: Anti-static ESD Knitted Polyester Fabric, 5mm Diamond
Applications: ESD protection in clean rooms, work wear
Features
1) Durable and light weight, with good air permeability, in weight 135g per square meter
2) This kind of garments/cap/boots/facemask which are sewed with esd fabric, offer extremely good resistance to static, chemicals and abrasion. It is designed for Class 100-1000 cleanrooms and higher. And it is applicable in medicals, biology.
3) Meets ESD standards, system resistance 10⁶–10⁷ ohms
Specifications
| Spec | Value | Test Method |
|---|---|---|
| Material | 96% Polyester 4% Carbon Fiber | |
| Available Colors | Dark Blue (Any color if Custom) | |
| Carbon Configuration | Diamond 5mm | |
| Width (cm) | 175 | |
| Weight (gr/sqm) | 135gsm | |
| Surface Resistivity (ohm/unit) | 10⁶–10⁷ | |
| Friction charges (V) | <150 | |
|
Number of yarns (denier) Warp Weft |
50DFDY*50DDTY |
|
| Weave style | Knitted | |
| Recommended Class Of Cleanroom | Class 100~1000 |
Our ESD Knitted Fabric Diamond Pattern Series
| Model | Spec | Yarn Count | Weight | Charge Density | Friction Voltage |
| AF0633 | Diamond 6mm | 50DFDY*50DDTY | 135-140gsm | 0.8uc/m | <200V |
| AF0632 | Diamond 5mm | 50DFDY*50DDTY | 135-140gsm | 0.8uc/m | <200V |
| AF0631 | Diamond 2.5mm | 50DFDY*50DDTY | 135-140gsm | 0.6uc/m | <150V |
More Photos
Related pages in Singapore
- Browse all ESD Fabric.
- Learn about ESDpro, our own ESD and cleanroom brand.
- Read our guides on ESD standards IEC 61340 and ANSI/ESD S20.20 and setting up an ESD grounded workstation.
Phil Industries, the Singapore company behind the ESDpro brand, supplies this product with selection advice and after-sales support. Call +65 6555 1745, WhatsApp +65 9853 9030 or email sales@phil-industries.com.sg.
Additional information
| ESD Classification | |
|---|---|
| Surface Resistance | 10⁶–10⁷ Ω |
