ESD PCB Magazine Rack – Top & Bottom Plate
| Brand Name: | ESDpro |
| Certification: | ISO/SGS |
| Model Number: | MR6605 |
- Description
- Reviews (0)
Description
This magazine rack ESD magazine rack is available in Singapore from Phil Industries. Easy Operation ESD PCB Magazine Rack Top And Bottom Pla provides reliable ESD protection for packaging and electronics manufacturing. As a supplier of ESD packaging materials in Singapore, Phil Industries offers island-wide delivery on all magazine rack ESD magazine rack products.
Detailed Product Description
Easy Operation ESD PCB Magazine Rack TopAnd Bottom Plastic Screw Adjustable
Model: MR6605
Description
1, Surface resistance: 10⁴–10⁸ Ohms(100-120℃)
2, External dimension: 355x320x563mm
3, Available for storing 50 pieces of PCB plates
4, Sizes of PCBs to be accommodated:355*(50-250)mm
5, Side guide slot, with depth of 3mm, width of 5.5mm and pitch of 10mm
6, The top and bottom boards are made of plastic
7, Plastic gear track designs allows easy operation
Features
1, Automation requires precision.
2, For the use of the PCB Magazines in automated assembly lines, precision, stability and flexible are our most important quality assurance.
3, The stable and robust frame construction guarantees a long lasting use of the magazine rack in your production.
4, The rack walls are manufactured from conductive materials, which could be temp resistance to 120degree around
Standard Size Table & Information
| Model NO. |
Base Material |
Adjust |
Heat-
Resistan Temp(℃) |
Outer Dimension
(mm) |
Adjustable
Width (mm) |
Ref.
Position (mm) |
Side board
structure |
Weight (kg) |
|||
| L | W | H | Material | structure | |||||||
| MR6601 | Metal | Gear
track |
100 | 400*320/380
*563 |
50-250/
300 |
34 | Polystyrene | Combined
panel |
7.2 | ||
| MR6602 | Plastic | Screw | 80 | 355*315*580 | 80-250 | 34 | Polystyrene | Whole panel | 5.1 | ||
| MR6602F | Metal | Screw | 80 | 355*315*580 | 80-250 | 34 | Polystyrene | Whole
panel |
5.2 | ||
| MR6603 | Metal | Gear
track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene | Combined
panel |
5.2 | ||
| MR6603G | Metal | Gear
track |
230 | 355*320*563 | 50-250 | 34 | Polycarbonate | Combined
panel |
7 | ||
| MR6603GL | Metal | Gear
track |
502 | 355*320*563 | 50-250 | 34 | Aluminum | Combined
panel |
6.7 | ||
| MR6604 | Metal | Screw | 100 | 355*320*563 | 50-250 | 34 | Polystyrene | Combined
panel |
5.1 | ||
| MR6604G | Metal | Screw | 230 | 355*320*563 | 50-250 | 34 | Polycarbonate | Combined
panel |
6.9 | ||
| MR6604GL | Metal | Screw | 502 | 355*320*563 | 50-250 | 34 | Aluminum | Combined
panel |
6.7 | ||
| MR6605 | Plastic | Gear
track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene | Combined
panel |
4.9 | ||
| MR6606 | Metal | Gear
track |
100 | 460*400*563 | 50-330 | 34 | Polystyrene | Combined
panel |
7.5 | ||
| MR6606G | Metal | Gear
track |
230 | 460*400*563 | 50-330 | 34 | Polycarbonate | Combined
panel |
9.7 | ||
| MR6607 | Metal | Screw | 100 | 460*400*563 | 50-330 | 34 | Polystyrene | Combined
panel |
7.4 | ||
| MR6607G | Metal | Screw | 230 | 460*400*563 | 50-330 | 34 | Polycarbonate | Combined
panel |
9.7 | ||
| MR6608 | Metal | Gear
track |
100 | 535*460*570 | 50-390 | 34 | Polystyrene | Combined
panel |
10.5 | ||
| MR6609 | Metal | Gear
track |
100 | 535*530*570 | 120-460 | 34 | Polystyrene | Combined
panel |
12.7 | ||
| MR6666 | Metal | Belt
drive |
100 | 355*320*563 | 50-250 | 34 | Polystyrene | Combined
panel |
7 | ||
| MR6663 | Metal | Gear
track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene | Whole
panel |
5.7 | ||
| MR6665 | Plastic | Gear
track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene | Whole
panel |
4.4 | ||
| MR6610 | Metal | Screw | 100 | 355*320*563 | 50-225
/75-225 |
34 | Polystyrene | Combined
panel |
7 | ||
| MR6611 | Metal | Gear
track |
100 | 355*320*363 | 50-250 | 34 | Polystyrene | Combined
panel |
4 | ||
| MR6603k | Metal | Gear
track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene | Combined
panel |
5.3 | ||
Our Pallet Pacakge for ref.
