Anti Static SMT ESD Magazine Rack PCB 400x320x380mm
| Brand Name: | ESDpro |
| Certification: | ISO/SGS |
| Model Number: | MR6603 |
- Description
- Additional information
- Reviews (0)
Description
This magazine rack ESD magazine rack is available in Singapore from Phil Industries. Anti Static Smt ESD Magazine Rack PCB 400x320x380mm provides reliable ESD protection for packaging and electronics manufacturing. As a supplier of ESD packaging materials in Singapore, Phil Industries offers island-wide delivery on all magazine rack ESD magazine rack products.
Detailed Product Description
400*320*380mm China Manufacturer Anti-Static SMT ESD PCB Magazine Circulation Rack
Description
| Material | Plastic and Metal |
| Surface resistance | 10e4-10e8ohms |
| Heat resistance | 100degree |
| External dimensions |
355*320*563mm (Availale for storing 50pcs of PCB plates) 400*320*380mm;355*320*563mm;355*315*580mm;460*400*563mm;535*460*570mm |
| Size of PCB to be accommodated | 355*(50-250)mmSide guide slot, with depth of 3mm, width of 5.5mm and pitch of 10mm The top and bottom boards are made of metal, screw adjustable design allows easy operation |
Features
1, Automation requires precision. For the use of the PCB Magazines in automated assembly lines, precision, stability and flexible
are our most important quality assurance;
2, The stable and robust frame construction guarantees a long lasting use of the magazine rack in your production;
3, The rack walls are manufactured from conductive materials, which could be temp resistance to 120degree around;
4, Usually, handling different PCB sizes, the magazines have to be adjusted according to the PCB width quite often. This style
gear belt will help you quick adjustments in seconds.
Standard Size Table & Information
| Model NO. |
Base Material |
Adjust |
Heat- Resistan Temp(℃) |
Outer Dimension (mm) |
Adjustable Width (mm) |
Ref. Position (mm) |
Side board structure |
Weight (kg) |
|||
| L | W | H | Material | structure | |||||||
| MR6601 | Metal |
Gear track |
100 |
400*320/380 *563 |
50-250/ 300 |
34 | Polystyrene |
Combined panel |
7.2 | ||
| MR6602 | Plastic | Screw | 80 | 355*315*580 | 80-250 | 34 | Polystyrene | Whole panel | 5.1 | ||
| MR6602F | Metal | Screw | 80 | 355*315*580 | 80-250 | 34 | Polystyrene |
Whole panel |
5.2 | ||
| MR6603 | Metal |
Gear track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene |
Combined panel |
5.2 | ||
| MR6603G | Metal |
Gear track |
230 | 355*320*563 | 50-250 | 34 | Polycarbonate |
Combined panel |
7 | ||
| MR6603GL | Metal |
Gear track |
502 | 355*320*563 | 50-250 | 34 | Aluminum |
Combined panel |
6.7 | ||
| MR6604 | Metal | Screw | 100 | 355*320*563 | 50-250 | 34 | Polystyrene |
Combined panel |
5.1 | ||
| MR6604G | Metal | Screw | 230 | 355*320*563 | 50-250 | 34 | Polycarbonate |
Combined panel |
6.9 | ||
| MR6604GL | Metal | Screw | 502 | 355*320*563 | 50-250 | 34 | Aluminum |
Combined panel |
6.7 | ||
| MR6605 | Plastic |
Gear track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene |
Combined panel |
4.9 | ||
| MR6606 | Metal |
Gear track |
100 | 460*400*563 | 50-330 | 34 | Polystyrene |
Combined panel |
7.5 | ||
| MR6606G | Metal |
Gear track |
230 | 460*400*563 | 50-330 | 34 | Polycarbonate |
Combined panel |
9.7 | ||
| MR6607 | Metal | Screw | 100 | 460*400*563 | 50-330 | 34 | Polystyrene |
Combined panel |
7.4 | ||
| MR6607G | Metal | Screw | 230 | 460*400*563 | 50-330 | 34 | Polycarbonate |
Combined panel |
9.7 | ||
| MR6608 | Metal |
Gear track |
100 | 535*460*570 | 50-390 | 34 | Polystyrene |
Combined panel |
10.5 | ||
| MR6609 | Metal |
Gear track |
100 | 535*530*570 | 120-460 | 34 | Polystyrene |
Combined panel |
12.7 | ||
| MR6666 | Metal |
Belt drive |
100 | 355*320*563 | 50-250 | 34 | Polystyrene |
Combined panel |
7 | ||
| MR6663 | Metal |
Gear track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene |
Whole panel |
5.7 | ||
| MR6665 | Plastic |
Gear track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene |
Whole panel |
4.4 | ||
| MR6610 | Metal | Screw | 100 | 355*320*563 |
50-225 /75-225 |
34 | Polystyrene |
Combined panel |
7 | ||
| MR6611 | Metal |
Gear track |
100 | 355*320*363 | 50-250 | 34 | Polystyrene |
Combined panel |
4 | ||
| MR6603k | Metal |
Gear track |
100 | 355*320*563 | 50-250 | 34 | Polystyrene |
Combined panel |
5.3 | ||
If you would like a HIGH-TEMP RESISTANT magazine rack, we have below 2 types for your options
Model: MR-6603G/Size: 355x320x563mm/Temp Resistance: 230degree
Related pages in Singapore
- Browse all ESD Packaging Materials.
- Learn about ESDpro, our own ESD and cleanroom brand.
- Read our guides on ESD matting for bench and floor and ESD standards IEC 61340 and ANSI/ESD S20.20.
Phil Industries, the Singapore company behind the ESDpro brand, supplies this product with selection advice and after-sales support. Call +65 6555 1745, WhatsApp +65 9853 9030 or email sales@phil-industries.com.sg.
Additional information
| ESD Classification | |
|---|---|
| Surface Resistance | 10⁴–10⁸ Ω |
