FG-OWC Preset Torque Screwdrivers
Mountz Torque FG -OWC (one-way clutch) torque screwdrivers use a one-way torque clutch system designed to apply torque in one direction and remain positive in the opposite direction, which allows the tool to be used for easy screw removal. Torque range suitable for micro, low, and medium torque applications.
This makes the FG-OWC ideal for maintenance and refurbishing applications where undoing or loosening screws is required.
Cam-over technology reduces the possibility of operator error in the clockwise fastening direction, which ensures correct torque is applied and prevents fastener breakage.
Providing the operator with a pre-set tool prevents tool tampering and ensures that the appropriate torque setting is always used.
With FG-OWC, you can Proceed with Confidence.
- Low-impact poka-yoke torque screwdriver prevents over-torque and vibration on sensitive components and delivers repeatability, traceability, and precision for all tightening applications.
- Preset screwdriver reduces the risk of operator tampering and ensures that the operator consistently applies the correct torque value to each fastener.
- Cam-over technology ensures correct torque is applied and reduces fastener breakage.
- Our tools are durable & reliable. We provide an Industry leading warranty: 2 years unconditional. Lifetime against defects. Calibration life 4x ISO standards, unmatched by any torque screwdriver.
- Description
Description
CHOOSE THE MODEL BELOW
| Model | Item Name / Number | Label Color | American | S.I. | Drive Size | |
|---|---|---|---|---|---|---|
 |
FG-8i OWC | 076586 | Blue | 0.8 – 8 lbf.in | 9 – 90 cN.m | 1/4″ F/Hex |
 |
FG-8i OWC | 076591 | Red | 0.8 – 8 lbf.in | 9 – 90 cN.m | 1/4″ F/Hex |
 |
FG-8i OWC | 076596 | Green | 0.8 – 8 lbf.in | 9 – 90 cN.m | 1/4″ F/Hex |
 |
FG-8i OWC | 076601 | Gold | 0.8 – 8 lbf.in | 9 – 90 cN.m | 1/4″ F/Hex |
|
FG-20i OWC | 076587 | Blue | 2 – 20 lbf.in | 22 – 226 cN.m | 1/4″ F/Hex |
|
FG-20i OWC | 076592 | Red | 2 – 20 lbf.in | 22 – 226 cN.m | 1/4″ F/Hex |
|
FG-20i OWC | 076597 | Green | 2 – 20 lbf.in | 22 – 226 cN.m | 1/4″ F/Hex |
|
FG-20i OWC | 076602 | Gold | 2 – 20 lbf.in | 22 – 226 cN.m | 1/4″ F/Hex |
 |
FG-40i OWC | 076588 | Blue | 4 – 40 lbf.in | 0.4 – 4.5 N.m | 1/4″ F/Hex |
 |
FG-40i OWC | 076593 | Red | 4 – 40 lbf.in | 0.4 – 4.5 N.m | 1/4″ F/Hex |
 |
FG-40i OWC | 076598 | Green | 4 – 40 lbf.in | 0.4 – 4.5 N.m | 1/4″ F/Hex |
 |
FG-40i OWC | 076603 | Gold | 4 – 40 lbf.in | 0.4 – 4.5 N.m | 1/4″ F/Hex |
|
FG-125i OWC | 076589 | Blue | 25 – 125 lbf.in | 2.8 – 14.1 N.m | 1/4″ F/Hex |
|
FG-125i OWC | 076594 | Red | 25 – 125 lbf.in | 2.8 – 14.1 N.m | 1/4″ F/Hex |
|
FG-125i OWC | 076599 | Green | 25 – 125 lbf.in | 2.8 – 14.1 N.m | 1/4″ F/Hex |
|
FG-125i OWC | 076604 | Gold | 25 – 125 lbf.in | 2.8 – 14.1 N.m | 1/4″ F/Hex |
Calibration and Preventative Maintenance
- View the calibration and preventative guidelines for Mountz torque screwdrivers.
CHOOSE THE MODEL BELOW
| Model: | Socket Head Power Bits 1/20 x 2″ |
| Item Name / Number: | 121039 |
| Bit Hex Size: | 1/20″ |
| Bit Length(IN): | 2″ |
| Package Quantity |
Error-Proofing:
-
-
- Engineered with a cam-over mechanism, cam-over poka-yoke torque screwdrivers reduce the possibility of operator error in the clockwise fastening direction, ensuring correct torque is applied and preventing fastener breakage.
- Providing the operator with a preset tool prevents tampering and ensures that operators always use the appropriate torque setting—unmatched security of the tamper-proof internal adjustment. No external adjustment scale—must be preset using a torque analyzer.
-
Process Improvement:
-
-
- Use color-coded label options for visible and easy-to-understand torque setting identification.
-
Ergonomics:
-
-
- Ergonomic handles are designed with fewer flutes and larger recesses to make the tools easier to hold, and less likely to cause hand fatigue.
-
Advanced Technology:
-
-
- Screwdriver is a one-way clutch system designed for the screwdriver to apply torque in one direction and lockup in the opposite direction for easy screw removal. Ideal for maintenance and refurbishing applications. OWC (one-way clutch) screwdriver torques in the CW direction only.
- Mountz torque unique bearing system eliminates axial load and sideloads on the fastener applied by the operator.
- Mountz tools use a patented secure bit locking mechanism with a one-touch release so that the operator can activate it to enable greater flexibility of applications and efficiency on the line.
- Reduced bit wear lowers the incidence of bits falling out, which can slow production or cause product damage.
- The new design improves serviceability, reduces downtime, and enables the replacement of individual parts to extend the life of your investment.
-
Mountz Quality Standards:
-
- Our tools are durable & reliable. We provide an Industry leading warranty: 2 years unconditional. Lifetime against defects.
- Calibration life is 4x ISO standard. Unmatched by any torque screwdriver.
- All Mountz-designed hand tools endure extensive Cmk testing over 20,000 continuous torque readings. Review our technical whitepaper to learn more!
The preferred and certified ranges of these tools is in accordance with the requirements of ISO 6789 (+/- 6% of indicated setting).
Calibration & Service:
-
- Torque Analyzers & Sensors: If torque tools slip out of calibration, that could impact the quality of your products. An accurate way to regularly test calibration onsite is a great way to reduce risk and ensure safety. With Mountz torque analyzers and sensors, you can test tools before they go into service daily or weekly.
- Prepaid Calibration Vouchers: Book service and maintenance in advance to ensure your tools are always in top condition and ready to use. Add this service to any tooling purchase.
Model : FG-8i OWC
Model: FG-20i OWC
Model: FG-40i OWC
Model: FG-125i OWC
