Woven Microfiber Cleanroom Wiper Plain Weave Basic 70% Polyester 30% Nylon
| Place of Origin: | China |
| Brand Name: | allesd |
| Certification: | ISO/SGS/ROHS |
| Model Number: | 3009 |
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 4″x4″; 400pcs/bag; 6″x6″, 100pcs/bag; 9″x9″, 100pcs/bag; 12″x12″, 100pcs/bag |
| Delivery Time: | 15-25days |
| Payment Terms: | T/T |
| Supply Ability: | ~100,000 BAGS per month |
- Description
Description
Detailed Product Description
Woven Microfiber Cleanroom Wiper Plain Weave Basic 70% Polyester 30% Nylon
Description:
They are comprised of 70% Polyester and 30% Nylon
Laser cut/Heat cut/Ultrasonic sealed edge maximize reduces fiber contamination
Extremely low levels of particulate and extractable counts.
Laundered by 18MΩ DI water and packaged in a ISO5 Cleanroom
Tested and manufactured in ISO compliant facilities
Features:
• Critically low particles, fibers, ions and extractables
• Leave no scratch on body’s sensitive surface
• Chemically compatible with IPA, Acetone and other solvents
• Complies with RoHS and REACH requirements
Technical Data:
| Spec | Value | Test Method |
|---|---|---|
| Size | 4” x 4”, 6” x 6”, 9” x 9”, 12” x 12” | |
| Material | 70% Polyester and 30% Nylon | |
| Basis weight | 100 or 85g/m2 | Electronic Balance Test |
| Liquid absorption ability | 235g/m2 | Referred to IES-RP-CC004.3 analysis method |
| Particle Counts LPC: ≥0.5 µm | 600 count /m2 | Tested by liquid particle analyzer |
|
IPA Extractant
|
1.432 µg/cm2
|
Measured by the weight of extract before and after volatilization |
|
DI Water Extractant
|
1.869 µg/cm2 | Measured by the weight of extract before and after volatilization |
RoHS Compliant:
| Ion | Average Value | Equipment Limit Test Value | Test Mehod |
| Chloride(Cl- ) | N.D. | 0.0010 µg/cm2 | test by ion chromatography(IC) |
| Sulfate(SO4 2-) | N.D. | 0.0010 µg/cm2 | test by ion chromatography(IC) |
| Sodium(Na+ ) | 0.0014 | 0.0010 µg/cm2 | test by ion chromatography(IC) |
| Ammonium(NH4+) | 0.0020 | 0.0010 µg/cm2 | test by ion chromatography(IC) |
| Fluoride(F) | 0.0010 | 0.0010 µg/cm2 | test by ion chromatography(IC) |
Woven Microfiber Wiper Main Catalogues:
|
NO.
|
Model
|
Description
|
Weaving process
|
Composition
|
Basic Weight
|
Sealing Method
|
Standard Package
|
|
1
|
7009 |
Woven Microfiber Wiper
|
Woven Matte |
70% Polyester and 30% Nylon
|
105g/㎡
|
Laser cut/Heat cut/Ultrosonic cut
|
100PCS/BAG, 20BAG/CTN
|
|
2
|
3009
|
Woven Microfiber Wiper
|
Woven Plain Weave
|
70% Polyester and 30% Nylon
|
100g/㎡
|
Laser cut/Heat cut/Ultrosonic cut
|
100PCS/BAG, 20BAG/CTN
|
|
3
|
3009A
|
Woven Microfiber Wiper
|
Woven Plain Weave
|
70% Polyester and 30% Nylon
|
85g/㎡
|
Laser cut/Heat cut/Ultrosonic cut
|
100PCS/BAG, 20BAG/CTN
|
|
4
|
7008
|
Woven Microfiber Wiper
|
Woven Twill
|
70% Polyester and 30% Nylon
|
120g/㎡
|
Laser cut/Heat cut/Ultrosonic cut
|
100PCS/BAG, 20BAG/CTN
|
Applications:
It is designed for critical processing applications where the high level of contamination control is required.
It is widely used for cleaning medical device products; applying, removing, cleaning and disinfecting solutions;
Also used for flat panel, optics cleaning and chips multiprocessing(CMP).
About Us
Established in 2011, Suzhou Quanjuda Purification Technology Co., LTD is a leading manufacturer and exporter of various ESD & Cleanroom products, offers a full line of ESD & Cleanroom equipment and supplies, providing comprehensive services by manufacturing, sourcing and exporting products from China.
Other Products we Supply
- Cleanroom Apparels(Disposable, Launderable)
- Cleanroom Cleaning Supplies(Wipes, Tacky Rollers, Mops, Brushes, Swabs),
- Cleanroom &ESD Chairs/Stools,
- Cleanroom Documentation(Paper, Pen, Notebook),
- Cleanroom Gloves(Finger Cots, PU Coated Glove, PVC Dotted Glove)
- Cleanroom Mats(Sticky Mat, Table/Floor Mat, Anti-fatigue Mat),
- ESD Package Materials(Bags, Tapes etc),
- ESD Storage Materials (Bins, Trays, Circulation Box, Solvent Dispensers),
- ESD Wrist/Heel Straps/Grounding Cords.
- Static Control Ionizing Blower/Gun/Nozzle,
- Illuminated Magnifier,
- Cleanroom Curtain and etc
